9006 Hybrid Control for RollerDrive
Assembly
Assembly
Warning notices concerning assembly
Do not drop or mishandle the 9006 to avoid internal damage.
Check each 9006 visually for damage before assembly.
Warning notices concerning the electrical installation
The electrical installation may only be executed by qualified and authorized
persons.
Disconnect the power before installing, removing or rewiring the 9006.
Do not apply AC current to the RollerDrive or 9006 device at any time
as this will cause irreparable damage.
Do not apply too much stress to the connector pins. Bending the wires at the
connector can cause damage to the insulation of the wires, which could result
in failure of the 9006 or the RollerDrive.
Ensure that the RollerDrive, the 9006 and the 24 VDC power source
are properly earthed through the frame or supporting structure in which the
RollerDrive and the 9006 are installed. Failure to do so could cause
the buildup of static electricity or ground loops and can cause the motor or
9006 to
malfunction or
fail prematurely.
Do not spin the RollerDrive manually, as this generates an induction voltage
which could damage the 9006.
Risk of damage leading to failure or shortened life
expectancy of the 9006
Observe the following notices.
Risk of damage to the 9006
Observe the following notices.
