Appendix
9006 Hybrid Control for RollerDrive
Appendix
Plugs and cables
Accessories
Part Description
Power and I/O plug • 8-pin cage clamp type connector, Wago part #
231-308/026-004
• Wire diameter:
– Minimum 0.08 mm
2
(AGW 28)
– Maximum 2.5 mm
2
(AGW 12)
Sensor plug • 6-pin cage clamp type connector, Wago part #
734-106/000-004
• Wire diameter:
– Minimum 0.08 mm
2
(AGW 28)
– Maximum 1.5 mm
2
(AGW 14)
Peer-to-peer cable • Cable: 6 pos flat cable, Digikey part # A0063R
(parts) • Two plugs: 6 pos modular connector plug,
Digikey part # A9093-ND
• Conductor Size AWG: 26
• Assembly tool: AMP part # 2-231652-8
Peer-to-peer cable • Complete cable: 6 pos flat cable,
(preassembled) with (2) 6 pin modular plugs,
Digikey part # A1663R-03-ND (03 = 3 foot length)
• www.digikey.com
Motor plug • The motor plug for the RollerDrive consists of
a
plug and terminal pins
– Plug: AMP part # 175778-8
– Terminal pins: AMP part # 1-175102-1
• Crimping tool AMP part # 9184381
