39
Version 1.1 (11/2011) en
Original language
9006 Hybrid Control for RollerDrive
Initial startup and operation
Initial startup and operation
Initial startup
Inspections before initial
startup
Ensure that all bolts are tightened according to the specifications.
Ensure that no additional dangerous areas arise due to interfaces with other
components.
Ensure that the wiring is in accordance with specifications and legal
guidelines.
Check all protection devices.
Ensure that no bystanders are in dangerous areas around the conveyor.
Operation
Inspections before every
startup
Check the position of the DIP switches (see "DIP switches", page 14).
Check the speed settings at the speed rotary switch. It is recommended to
run the RollerDrive at maximum speed.
Check the 9006 for visible damage.
Check all protection devices.
Ensure that no bystanders are in dangerous areas around the conveyor.
Clearly specify and monitor the way goods are placed on the conveyor.
Changing settings
To reduce the speed manually, turn the rotary switch counterclockwise with a
small screwdriver.
To increase the speed manually, turn the rotary switch clockwise with a small
screwdriver.
To set the DIP switches, carefully use a small screwdriver.
Procedure in case of accident or malfunction
Stop the conveyor at once and ensure that it cannot be started accidentally.
In case of an accident: Provide first aid and call for emergency assistance.
Inform responsible persons.
Have the malfunction repaired by qualified persons.
Start the conveyor only after this has been approved by qualified persons.
Damage to the 9006 or the motor of the
RollerDrive due to induction
Do not push items along the roller conveyor by hand.
Do not spin the RollerDrive manually.
