4. Installation Procedures
80
Radio Unit Ethernet (S-FTP) Cable, Continued
Procedure,
continued
6 Perform the following actions:
A: Insert the seal into “pressure fingers” of claw.
B: Insert the O-ring.
C:
Screw the sealing nut. Use the adjustable torque U-
The ring protects from overtightening.
Continued on next page
