6 SET-UP
Part No 1153410
35 Invacare ®CS Series Beds
Install Head and Foot Ends
All Models Except CS9FX600 Model CS9FX600
9. 76 in Bed Only - Tighten the fasteners with two
7/16 in wrenches. Reposition the other three
brackets and reapply the ends.
10. Position the mattress on the deck.
11. Press the mattress inside the mattress keeper. Ensure the mattress is engaged on all four corners.
Head and foot ends are normally packaged together either in a cardboard box or on a wooden skid separate from the bed.
Bed end model IHBEADJ must be used with bed model CS9FX600. Refer to Adjusting the Head Board Width for
CS9FX600 on page 62.
