Invacare POC1–100B-C - 4.5 Replacing DC Power Cable Fuse

Service
8.Installnewpatientoutletlterintotheundersideof
thebarbedcap.
Gentlypresssealinplaceagainstthesealing
surface.Becarefulnottorupturethelter
element.
9.CleanT-20driverwithalcoholpad.
10.ReinstallbarbedcapandhandtightenwithT-20driver
untilthebarbedcaptsrmlyagainstthelowerhalf
oftheoxygenoutletport.
Becarefulnottocrossthethreadswhenstarting
toinstallthecap.
11.Reinstallunitintocarrybag.
12.Reinstallbatterypack(s).
13.Closethebatterycompartmentdoor .
14.Testtheconcentratorfunction.RefertoFunctionTest
inMaintenance.
4.5ReplacingDCPowerCableFuse
WARNING!
RiskofInjuryorDamage
–EnsurethattheDCpowercableisdisconnected
fromDCpower.
–DONOTreplacefuseiftheDCpowercableis
hot.
OnlyusefusesprovidedbyInvacare.
TheDCpowercabledoesnotworkunlessitis
assembledcorrectly.
–Whenreplacingthefuse,donotloseany
ofthesmallpiecesandmakesuretheyare
reassembledcorrectly.
1187375-B19
