Invacare POC1–100B-C - 1.2.2 Input;Output Connections

General
G
BatteryGauge
Indicatesthechargestatusofthebattery(s).Refer
toReadingtheBatteryGaugeforInstalledand
UninstalledBattery(s)inSetupformoredetails.
H
ExternalPowerIndicator
Theorangeindicatorlightnexttotheplugsymbol
illuminateswhenanexternalpowersourceis
connectedtotheconcentrator .
I
BatteryCompartmentDoor
Usedtoaccesstheremovablebattery(s).
Not
Shown
AudibleSignal(Beep)
Indicatesachangeinoperatingstatusor
aconditionwhichrequirestheoperator’s
attention.
1.2.2Input/OutputConnections
A
OxygenOutletPort
Usedtoconnectthenasalcannulatothe
concentrator.
B
ExternalPowerInputConnector
Usedtoconnectanexternalpowersourcetothe
concentrator.
C
USBPort
Usedforserviceonly.
