Invacare POC1–100B-C - 4.6 Replacing the Battery Pull Ring

Invacare®Platinum®Mobile
1.UseplierstounscrewandremovetheendpieceE
fromtheDCpowercableF.
ThetipGwillcomeoffaswell.
2.RemovetheexistingfuseHfromtheDCpowercable.
ThespringImaycomeoutoftheDCpower
cablewhenthefuseisremoved.
3.EnsurethespringisinstalledintotheDCpowercable.
4.SeatthefuseintothetipG.
5.PlacethetipintotheendpieceE.
6.Slidetheassemblyoffuse,tipandendpieceintothe
DCpowercable.
7.TightlyscrewtheendpieceontotheDCpowercable.
8.Ensurepropercablefunction.
4.6ReplacingtheBatteryPullRing
1.Lifttheroundedendoftheexistingpullring.
2.Slidetheexistingpullringoutofitsmount.
201187375-B
