Setup
ThemastassemblyAmayberemovedfromthe
baseBforstorageortransporting.Themast
assemblyMUSTbeproperlysecuredtothebase
assemblybeforeuse.
1.PutthebaseBonalevelsurfacesoallcastersCmake
contactwiththeoor.
2.Locktherearcasters.RefertoLocking/Unlockingthe
RearCastersintheUsagesectionofthemanual.
H
F
G
I
D
E
3.UnscrewthetopknobDandremoveitfromthebase.
4.LoosenthebottomknobE,butleaveitscrewedinto
thebase.
5.ConnectthemastassemblycableFtothebasecable
G.
WARNING!
Riskofinjury
–DONOTplacehandsbetweenthemast
andbaseduringassembly.
CAUTION!
RiskofDamage.
–DONOTcrushtheconnectedcables
betweenthemastandbaseduring
assembly.
6.PutthetubeofthemastassemblyHintotheholein
thebaseI.
7.Whilesupportingthemastassembly,tightenthebottom
plasticknob.
8.Screwthetopplasticknobintotheholeinthebase.
9.ReverseSTEPS3–8todisassemblethemastfromthe
base.
1195052-B19
