4 OPERATION
Part No 1154295 45 Invacare® Solara®3G/Spree 3G Wheelchair
FIGURE10 Using the Pull to Lock Wheel Locks
Wheel Lock
Handle
Wheel Lock
Handle
Locked Position
Side View
Unlocked Position
Side View
Locked Position
Top View
Wheel
Lock Shoe
Wheel Lock
Shoe
Wheel Lock
Handle
Wheel Lock
Shoe
Wheel Lock
Handle
Wheel Lock
Shoe
Unlocked
Position
Top View
