4 OPERATION
Invacare® Solara®3G/Spree 3G Wheelchair 46 Part No 1154295
FIGURE11 Using the Push to Lock Wheel Locks
Wheel Lock
Handle
Wheel Lock
Handle
Locked Position Side View
Unlocked Position
Side View
Locked Position
Top View
Wheel
Lock Shoe
Wheel Lock Shoe
Wheel Lock
Handle
Wheel Lock Shoe
Wheel Lock
Handle
Wheel
Lock Shoe
Unlocked Position
Top View
