5 TRANSPORT READY OPTION
Part No 1154295 65 Invacare® Solara®3G/Spree 3G Wheelchair
Vehicle-Anchored Belts
This wheelchair has an overall rating of “B” with regard to accommodating the use and fit of vehicle-anchored belts. This rating is scored as follows:
The test for Lateral Stability Displacement for Point (P) is shown in FIGURE4. The average test result for point (P) is 0.65-inches (16.5 mm).
FIGURE4 Vehicle-Anchored Belts
RATING DESCRIPTION
A Excellent
B Good
C Fair
D Poor
NOTE: Rear view of wheelchair and human
surrogate secured on test platform and
tilted to 45 degrees.
Rear View
Test
Platform
Point (P)
45°
