48
8.4. Power supply output for analog sensor
Output voltage 3.3 V
Maximum output current 150 mA
Minimum activity period 50 s
Maximum activity period
120 s
300 s (active connection with spooler
or logger data transmission)
Voltage settling time (before the
measurement)
40 s
8.5. Binary inputs I1, I2
Contact polarisation voltage 2.5 V
Counting frequency 30 Hz max.
Minimum pulse width 16 ms
8.6. Analog inputs A1, A2
Measuring range 0-3.3 V
Input resistance
>200 k
typical
Resolution 10 bits
Accuracy ±1%
8.7. Internal logger
Memory type FLASH
Maximum number of records 288
Minimum recording time 5 min.
