30
6.1.5.1.1.3. Module activation
Function - Defines the method of the module activation
Data type - Selection list
Variation
range
- Yes
The binary input state change causes the module
activation and starts the processing of rules
No
The function is disabled
Default
value
- No
Comment - Setting this parameter to Yes causes asynchronous and
unconditional wake-up the module when the input state
changes from logical 0 to 1. Such configuration allows to use
the binary input as an asynchronous alarm trigger, useful in
many situations (for example in guard systems)
6.1.5.1.1.4. Counter
Function - Defines the additional totalizing function of the binary input
Data type - Selection list
Variation
range
- Yes
The binary input operates as a counter input. Each pulse
appearing on the input increases the 32-bits counter
content
No
The function is disabled
Default
value
- No
Comment - Total capacity of the counter: 4294967296 pulses. Pushing
the RESET button clears the counter.
ATTENTION!!!
There is a possibility to enter an initial value into the counter
to provide the synchronization between the countercontent
and the value already recorded in the connected mechanical
counter.
6.1.5.1.1.5. Pulse weight
Function - The weight of a single pulse count on the counter input (for
example the weight is defined in liters in case of flow meter
pulses counting)
Data type - Number
Variation
range
- 1…65535
Default
value
- 1
Comment - This parameter allows to compute the initial value of the
counter content according to the units set for the counter
(for example, it may be expressed in liters in case of water
meters). It should be set BEFORE the Initial setup of the
counter associated with the binary input
