INVENTIA MT-703 User Manual

52

10.3. Memory map
Internal registers (read 3)
Address
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Description Write
0x04
(4)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
I3FE I2FE I1FE I3RE I2RE I1RE I3 I2 I1
Binary inputs
IxRE - rising edge
flag
IxFE - falling edge
flag
No
0x05
(5)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Binary outputs
(not implemented)
No
0x06
(6)
CNT1_H
Counter I1
(High byte)
No
0x07
(7)
CNT1_L
Counter I1
(Low byte)
No
0x08
(8)
CNT2_H
Counter I2
(High byte)
No
0x09
(9)
CNT2_L
Counter I2
(Low byte)
No
0x0A
(10)
CNT1_INC
I1 counter
increment
No
0x0B
(11)
CNT2_INC
I2 counter
increment
No
0x0C
(12)
CNT1_UNIT
Pulse weight
counter I1
No
0x0D
(13)
CNT2_UNIT
Pulse weight
counter I2
No
0x0E
(14)
AN1_E
Analog input AN1
internal units
No
0x0F
(15)
AN2_E
Analog input AN2
internal units
No
0x10
(16)
AN1_E
Analog input AN1
engineering units
No
0x11
(17)
AN2_E
Analog input AN2
engineering units
No
0x12
(18)
VBAT Battery voltage No
0x13
(19)
SIGNAL LEVEL
GSM signal level
(from 0 to 31)
No
0x14
(20)
GPRS_LOG_F_CNT
Failed GSM login
counter
No
0x15
(21)
GPRS_FRAME_UNACK Lost frame counter No
0x16
(22)
LOGGER RECORD NO
Consecutive
number of logger
record
(regards the
logger frames
only)
No
