INVT DA180-S5R0SG0

DA180 series basic AC servo drive Function codes
-225-
R1.05
Corrected voltage of AI 1
Setting range
Accuracy
Unit
-10.000–10.000
0.001
V
This parameter displays the corrected voltage of the analog input channel 1.
R1.05
Data size
32bit
Data format
DEC
Modbus address
4210, 4211
CANopen address
0x3105, 0x00
R1.06
Corrected voltage of AI 2
Setting range
Accuracy
Unit
-10.000–10.000
0.001
V
This parameter displays the corrected voltage of the analog input channel 2.
R1.06
Data size
32bit
Data format
DEC
Modbus address
4212, 4213
CANopen address
0x3106, 0x00
R1.08
Voltage of AO 1
Setting range
Accuracy
Unit
-10.000–10.000
0.001
V
This parameter displays the biased voltage of the analog output channel 1.
R1.08
Data size
32bit
Data format
DEC
Modbus address
4216, 4217
CANopen address
0x3108, 0x00
R1.09
Voltage of AO 2
Setting range
Accuracy
Unit
-10.000–10.000
0.001
V
This parameter displays the biased voltage of the analog output channel 2.
R1.09
Data size
32bit
Data format
DEC
Modbus address
4218, 4219
CANopen address
0x3109, 0x00
R1.11
Accumulated input
pulses
Setting range
Accuracy
Unit
-(2
31
-1)–(2
31
-1)
1
reference unit
This parameter accumulates and displays the number of pulses that are received from the external
pulse input.
R1.11
Data size
32bit
Data format
DEC
Modbus address
4222, 4223
CANopen address
0x310B, 0x00
R1.12
Pulse position command
Setting range
Accuracy
Unit
-(2
31
-1)–(2
31
-1)
1
reference unit
This parameter displays the position command value in each pulse input detection cycle (0.125ms
by default).
R1.12
Data size
32bit
Data format
DEC
Modbus address
4224, 4225
CANopen address
0x310C, 0x00
