INVT GD10-0R7G-4-B User Manual

Goodrive10 Series Mini VFD Communication protocol
-95-
Function instruction
Address
definition
Data meaning instruction
R/W
characteristics
0005H: POFF state
VFD state word 2
2101H
Bit0: =0: Bus voltage is not
established =1: Bus voltage is
established
Bi1–2:=00: Motor 1
Bit3: =0: Asynchronous motor
=1: Synchronous motor
Bit4:=0: Pre-alarm without
overload =1: Overload
pre-alarm
Bit5–Bit6:=00: Keypad control
=01: Terminal control
=10: Communication
control
R
VFD fault code
2102H
See the description of fault
types.
R
VFD identification
code
2103H
Goodrive10-----0x010d
R
Running frequency
3000H
0–Fmax (unit:
0.01Hz)
Compatible
with GD
series,
CHF100A and
CHV100
R
Set frequency
3001H
0–Fmax (unit:
0.01Hz)
R
Bus voltage
3002H
0.0–2000.0V
(unit: 0.1V)
R
Output voltage
3003H
0–1200V (unit:
1V)
R
Output current
3004H
0.0–3000.0A
(unit: 0.1A)
R
Rotating speed
3005H
0–65535 (unit:
1RPM)
R
Output power
3006H
-300.0–300.0%
(unit: 0.1%)
R
Output torque
3007H
-250.0–250.0%
(unit: 0.1%)
R
PID setting
3008H
-100.0–100.0%
(unit: 0.1%)
R
PID feedback
3009H
-100.0–100.0%
(unit: 0.1%)
R
Input IO state
300AH
000–1FF
R
Output IO state
300BH
000–1FF
R
Analog input 1
300CH
0.00–10.00V
R
