Goodrive10 Series Mini VFD Function parameters
-61-
Function
code
Name
Description
Default
Modify
1: Valid during running, cleared after stopping
2: Valid during running, cleared after receiving
the stop command
LED thousands: ∧ / ∨ keys and digital
potentiometer Integral function
0: The integral function is valid
1: The integral function is invalid
P08.44
UP/DOWN
terminals
control
setting
0x00–0x221
LED ones: frequency enabling selection
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting invalid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: When the multi-step are priority, it is invalid
to the multi-step
LED hundreds: action selection when stop
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving
the stop commands
0x000
○
P08.45
Frequency
increment
integral rate
of the UP
terminal
0.01–50.00s
0.50s
○
P08.46
Frequency
integral rate
of the DOWN
terminal
0.01–50.00s
0.50s
○
P08.47
Action
selection for
frequency
settings on
power off
0x000–0x111
LED ones: Action for digital adjustable
frequency on power off
0: Save on power off
1: Clear on power off
LED tens: Action for Modbus frequency
setting on power off
0x000
○
