INVT GD300L-1R5G-S2 User Manual

Goodrive300-LIFT series inverter Expansion cards
-147-
Function
code
Name
Detailed parameter description
Default
value
Modify
32: Short-to-ground fault 1 (ETH1)
33: Short-to-ground fault 2 (ETH2)
34: Speed deviation fault (dEu)
35: Maladjustment (STo)
36: Undervoltage fault (LL)
37: Encoder offline fault (ENC1O)
38: Encoder reverse fault (ENC1D)
39: Encoder Z pulse offline fault (ENC1Z)
40: U disconnection (ENC1U)
41–42: Reserved
43: Motor overtemperature fault (OT)
44: Reserved
45: Braking fault (BAE)
46: Contactor fault (CONE)
47: No CD signal (nPoS)
48: No enabling signal (U-EN)
49: STO card fault (SAFE)
50: Channel 1 (STO1_FB_DSP) safety circuit
exception (STL1)
51: Channel 2 (STO1_FB_DSP) safety circuit
exception (STL2)
52: Internal circuit exception (STL3)
53: Safety code FLASH CRC fault (CrCE)
P15.00
Expansion card
type
0: No
1: STO
2: IO
3: Bluetooth
0
