INVT GD300L-1R5G-S2 User Manual

Goodrive300-LIFT series inverter Function parameters
-52-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P07.06
Selection 1 of
parameters
displayed in
running state
0x0000–0xFFFF
Bit0: Running speed
Bit1: Set speed
Bit2: Bus voltage
Bit3: Output voltage (V on)
Bit4: Output current (A on)
BIT5: Set frequency (Hz on)
BIT6: Running frequency (Hz on)
BIT7: Running rotation speed
BIT8: Output power (% on)
BIT9: Output torque (% on)
BIT10: Input terminal state
BIT11: Output terminal state
BIT12: AI1 (% on)
BIT13: AI2 (% on)
BIT14: Magnetic pole position
Bit15: Linear speed
0x07F
○
P07.07
Selection 2 of
parameters
displayed in
running state
Reserved
0x0000
○
P07.08
Selection of
parameters
displayed in stop
state
0x0000–0xFFFF
BIT0: Set speed
BIT1: Set frequency
BIT2: Bus voltage
BIT3: Input terminal state
BIT4: Output terminal state
BIT5: AI1
BIT6: AI2
BIT7: Magnetic pole position
BIT8–BIT15: Reserved
0x007F
○
P07.09
Speed display
coefficient
0.0–300.0%
100.0%
○
P07.10
Rectifier bridge
module
temperature
0–100.0˚C
0.0
●
P07.11
Converter
module
temperature
0–100.0˚C
0.0
●
P07.12
Software version
1.00–655.35
0.00
●
P07.13
Local
accumulative
running time (h)
0–65535h
0
●
