INVT GD300L-1R5G-S2 User Manual

Goodrive300-LIFT series inverter Function parameters
-53-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P07.14
Local
accumulative
running time
(min)
0–60min
0
●
P07.15
MSB of local
accumulative
running count
0–65535 (P07.15×10000 + P07.16)
0
●
P07.16
LSB of Local
accumulative
running count
0–10000
0
●
P07.17
MSB of inverter
power
consumption
0–65535 kWh (×1000)
0
●
P07.18
LSB of inverter
power
consumption
0.0–999.9 kWh
0.0
●
P07.19
Inverter rated
power
0.4–3000.0kW
0.0
●
P07.20
Inverter rated
voltage
50–1200V
0
●
P07.21
Inverter rated
current
0.1–6000.0A
●
P07.22
Factory bar code
1
0x0000–0xFFFF
●
P07.23
Factory bar code
2
0x0000–0xFFFF
●
P07.24
Factory bar code
3
0x0000–0xFFFF
●
P07.25
Factory bar code
4
0x0000–0xFFFF
●
P07.26
Factory bar code
5
0x0000–0xFFFF
●
P07.27
Factory bar code
6
0x0000–0xFFFF
●
