Function
code
Name
Detailed parameter description
Default
value
Modi
fy
switch-on delay
Si electrical level
Si valid
invalid invalid
Switcn-on
delay
Switcn-off
delay
valid
Setting range: 0.000–50.000s
P05.15
S2 terminal
switch-off delay
0.000s
○
P05.16
S3 terminal
switch-on delay
0.000s
○
P05.17
S3 terminal
switch-off delay
0.000s
○
P05.18
S4 terminal
switch-on delay
0.000s
○
P05.19
S4 terminal
switch-off delay
0.000s
○
P05.20
HDIA terminal
switch-on delay
0.000s
○
P05.21
HDIA terminal
switch-off delay
0.000s
○
P05.22
HDIB terminal
switch-on delay
0.000s
○
P05.23
HDIB terminal
switch-off delay
0.000s
○
P05.24
Lower limit value
of AI1
These function codes define the relation between
analog input voltage and corresponding set value of
analog input. When the analog input voltage
exceeds the range of max./min. input, the max. input
or min. input will be adopted during calculation.
When analog input is current input, 0–20mA current
corresponds to 0–10V voltage.
In different applications, 100% of analog setting
corresponds to different nominal values.
The figure below illustrates several settings.
-100%
100%
Corresponding setting
AI
-10V
10V
20mA
0
AI2
AI1
Input filter time: Adjust the sensitivity of analog input,
0.00V
○
P05.25
Corresponding
setting of lower
limit of AI1
0.0%
○
P05.26
Upper limit value
of AI1
10.00V
○
P05.27
Corresponding
setting of upper
limit of AI1
100.0%
○
P05.28
Input filter time of
AI1
0.030s
○
P05.29
Lower limit value
of AI2
-10.00V
○
P05.30
Corresponding
setting of lower
limit of AI2
-100.0%
○
P05.31
Intermediate
value 1 of AI2
0.00V
○
