INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-153-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
input filter time
P05.44
HDIB high-speed
pulse input
function selection
0: Set input via frequency
1: Reserved
2: Encoder input, it should be used in combination
with HDIA
0
◎
P05.45
Lower limit
frequency of
HDIB
0.000 KHz – P05.47
0.000
KHz
○
P05.46
Corresponding
setting of lower
limit frequency of
HDIB
-100.0%–100.0%
0.0%
○
P05.47
Upper limit
frequency of
HDIB
P05.45 –50.000KHz
50.000
KHz
○
P05.48
Corresponding
setting of upper
limit frequency of
HDIB
-100.0%–100.0%
100.0%
○
P05.49
HDIB frequency
input filter time
0.000s–10.000s
0.030s
○
P05.50
AI1 input signal
type
0–1
0: Voltage type
1: Current type
0
◎
P05.51–
P05.52
Reserved
variables
0–65535
0
●
P06 group Output terminals
P06.00
HDO output type
0: Open collector high-speed pulse output
1: Open collector output
0
◎
P06.01
Y output
selection
0: Invalid
1: In running
2: In forward running
3: In reverse running
4: In jogging
5: Inverter fault
6: Frequency level detection FDT1
7: Frequency level detection FDT2
8: Frequency reached
0
○
P06.02
HDO output
selection
0
○
P06.03
Relay RO1
output selection
1
○
P06.04
Relay RO2
output selection
5
○
