INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-174-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
P10.18
Multi-step speed 8
function code P05.01–P05.06) and correspond to
multi-step speed 0 to multi-step speed 15.
Output frequency
t
t
t
t
t
Terminal 1
Terminal 2
Terminal 3
Terminal 4
When terminal 1, terminal 2, terminal 3 and terminal
4 are OFF, the frequency input mode is set by
P00.06 or P00.07. When terminal 1, terminal 2,
terminal 3 and terminal 4 are not all OFF, the
frequency set by multi-step speed will prevail, and
the priority of multi-step setting is higher than that of
the keypad, analog, high-speed pulse, PID, and
communication settings.
The relation between terminal 1, terminal 2, terminal
3 and terminal 4 are shown in the table below.
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
Step
0
1
2
3
4
5
6
7
Terminal 1
OFF
ON
OFF
ON
OFF
ON
OFF
ON
Terminal 2
OFF
OFF
ON
ON
OFF
OFF
ON
ON
Terminal 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
Terminal 4
ON
ON
ON
ON
ON
ON
ON
ON
Step
8
9
10
11
12
13
14
15
0.0%
○
P10.19
Running time of
8
th
step
0.0s(min)
○
P10.20
Multi-step speed 9
0.0%
○
P10.21
Running time of
9
th
step
0.0s(min)
○
P10.22
Multi-step speed
10
0.0%
○
P10.23
Running time of
10
th
step
0.0s(min)
○
P10.24
Multi-step speed
11
0.0%
○
P10.25
Running time of
11
th
step
0.0s(min)
○
P10.26
Multi-step speed
12
0.0%
○
P10.27
Running time of
12
th
step
0.0s(min)
○
P10.28
Multi-step speed
13
0.0%
○
P10.29
Running time of
13
th
step
0.0s(min)
○
P10.30
Multi-step speed
14
0.0%
○
P10.31
Running time of
14
th
step
0.0s(min)
○
P10.32
Multi-step speed
15
0.0%
○
P10.33
Running time of
15
th
step
0.0s(min)
○
P10.34
Acceleration/dec
eleration time of
0
th
–7
th
step of
simple PLC
Detailed illustration is shown in the table below.
Function
code
Binary
Step
number
ACC/
DEC
time 1
ACC/
DEC
time 2
ACC/
DEC
time 3
ACC/
DEC
time 4
P10.34
BIT1
BIT0
0
00
01
10
11
BIT3
BIT2
1
00
01
10
11
BIT5
BIT4
2
00
01
10
11
BIT7
BIT6
3
00
01
10
11
0x0000
○
P10.35
Acceleration/dec
eleration time of
0x0000
○
