INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-178-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
Enable and define overload pre-alarm function of the
inverter and motor
Setting range: 0x000–0x131
Ones:
0: Motor overload/underload pre-alarm, relative to
rated motor current;
1: Inverter overload/underload pre-alarm, relative to
rated inverter current.
Tens:
0: The inverter continues running after
overload/underload alarm;
1: The inverter continues running after underload
alarm, and stops running after overload fault;
2: The inverter continues running after overload
alarm, and stops running after underload fault;
3: The inverter stops running after overload/underload
fault.
Hundreds:
0: Always detect
1: Detect during constant-speed running
Setting range of P11.09: P11.11–200%
Setting range of P11.10: 0.1–3600.0s
P11.11
Underload
pre-alarm
detection level
Underload pre-alarm signal will be outputted if the
output current of the inverter or motor is lower than
underload pre-alarm detection level (P11.11), and
the duration exceeds underload pre-alarm detection
time (P11.12).
Setting range of P11.11: 0– P11.09
Setting range of P11.12: 0.1–3600.0s
50%
○
P11.12
Underload
pre-alarm
detection time
1.0s
○
P11.13
Fault output
terminal action
during fault
This function code is used to set the action of fault
output terminals during undervoltage and fault reset.
0x00–0x11
Ones:
0: Act during undervoltage fault
1: Do not act during undervoltage fault
Tens:
0: Act during fault reset
1: Do not act during fault reset
0x00
○
P11.14
Speed deviation
0.0–50.0%
10.0%
○
