Function
code
Name
Detailed parameter description
Default
value
Modi
fy
P18.08
Position of
position
reference point
Position of reference point of Z pulse when the
spindle stops accurately.
Range: 0–65535
0
●
P18.09
Current position
setup of spindle
Current position setup when the spindle stops
accurately.
Range: 0–359.99
0.00
●
P18.10
Current position
when spindle
stops accurately
Current position when spindle stops accurately.
Range: 0–65535
0
●
P18.11
Encoder Z pulse
direction
Z pulse direction display. When the spindle stops
accurately, there may be a couple of pulses’ error
between the position of forward and reverse
orientation, which can be eliminated by adjusting Z
pulse direction of P20.02 or exchanging phase AB
of encoder.
0: Forward
1: Reverse
0
●
P18.12
Encoder Z pulse
angle
Reserved.
Range: 0.00–359.99
0.00
●
P18.13
Encoder Z pulse
error times
Reserved.
Range: 0–65535
0
●
P18.14
High bit of
encoder pulse
count value
0–65535
0
●
P18.15
Low bit of
encoder pulse
count value
0–65535
0
●
P18.16
Reserved
variables
0–65535
0
●
P18.17
Pulse command
frequency
Pulse command (A2, B2 terminal) is converted to the
set frequency, and it is valid under pulse position
mode and pulse speed mode.
Range: 0–655.35Hz
0.00Hz
●
P18.18
Pulse command
feedforward
Pulse command (A2, B2 terminal) is converted to the
set frequency, and it is valid under pulse position
mode and pulse speed mode.
Range: 0–655.35Hz
0.00Hz
●
P18.19
Position regulator
output
The output frequency of the position regulator during
position control.
Range: 0–65535
0
●
