INVT Goodrive350 Series

Goodrive350 series high-performance multi-function inverter Chapter 6
-194-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
P18.20
Count value of
resolver
Count value of resolver.
Range: 0–65535
0
●
P18.21
Resolver angle
The pole position angle read according to the
resolver-type encoder.
Range: 0.00–359.99
0.00
●
P18.22
Pole angle of
closed-loop
synchronous
motor
Current pole position.
Range: 0.00–359.99
0.00
●
P18.23
State control
word 3
0–65535
0
●
P18.24
High bit of count
value of pulse
reference
0–65535
0
●
P18.25
Low bit of count
value of pulse
reference
0–65535
0
●
P18.26
Spindle reduction
ratio
It is the drive ratio (speed ratio) between the
mounting shaft and the spindle of the encoder when
spindle stops accurately.
Range: 0.000–65.535
0.000
●
P18.27
Encoder UVW
sector
0–7
0
●
P18.28
Encoder PPR
(pulse-per-
revolution)
display
0–65535
0
●
P18.29
Angle
compensation
value of
synchronous
motor
-180.0–180.0
0.00
●
P18.30
Reserved
variables
0–65535
0
●
P18.31
Pulse reference
Z pulse value
0–65535
0
●
P18.32–
P18.35
Reserved
variables
0–65535
0
●
P19 group Extension card state check
