Goodrive350 series high-performance multi-function inverter Chapter 5
-60-
Note: This kind of V/F curve separation can be applied in various frequency-conversion power
sources, however, users should be cautious of parameter setup as improper setup may damage the
machine.
Detailed parameter description
0:SVC 0
1:SVC 1
2:SVPWM
3:VC
Note: If 0, 1 or 3 is selected, it is required to
carry out motor parameter autotuning first.
Upper limit of running
frequency
Lower limit of running
frequency
0: Asynchronous motor
1: Synchronous motor
Rated power of asynchronous
motor 1
0.01Hz–P00.03 (max. output frequency)
Rated voltage of
asynchronous motor 1
V/F curve setting of motor 1
0: Straight-type V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve (power 1.3)
3: Torque-down V/F curve (power 1.7)
4: Torque-down V/F curve (power 2.0)
5: Customized V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
Motor 1 torque boost cut-off
0.0%–50.0% (rated frequency of motor 1)
V/F frequency point 1 of
motor 1
V/F voltage point 1 of motor 1
V/F frequency point 2 of
motor 1
V/F voltage point 2 of motor 1
