Goodrive350 series high-performance multi-function inverter Chapter 5
-61-
Detailed parameter description
V/F frequency point 3 of
motor 1
P04.05– P02.02 or P04.05– P02.16
V/F voltage point 3 of motor 1
V/F slip compensation gain of
motor 1
Low-frequency oscillation
control factor of motor 1
High-frequency oscillation
control factor of motor 1
Oscillation control threshold
of motor 1
0.00Hz–P00.03 (max. output frequency)
V/F curve setup of motor 2
0: Straight V/F curve;
1: Multi-point V/F curve
2: Torque-down V/F curve (1.3
th
order)
3: Torque-down V/F curve (1.7
th
order)
4: Torque-down V/F curve (2.0
th
order)
5: Customize V/F (V/F separation)
0.0%: (automatic) 0.1%–10.0%
Motor 2 torque boost cut-off
0.0%–50.0% (rated frequency of motor 1)
V/F frequency point 1 of
motor 2
V/F voltage point 1 of motor 2
V/F frequency point 2 of
motor 2
V/F voltage point 2 of motor 2
V/F frequency point 3 of
motor 2
P04.18– P02.02 or P04.18– P02.16
V/F voltage point 3 of motor 2
V/F slip compensation gain of
motor 2
Low-frequency oscillation
control factor of motor 2
High-frequency oscillation
control factor of motor 2
Oscillation control threshold
of motor 2
0.00Hz–P00.03 (max. output frequency)
0: No
1: Automatic energy-saving run
