INVT SPC Series User Manual

SPC Series Solar Pump Inverter Keypad operation guidelines
-14-
No.
Name
Description
Blinking: in pre-alarm state
On: in fault state
2
Unit
indicator
Unit displayed currently
Hz
Frequency unit
RPM
Rotation speed unit
A
Current unit
%
Percentage
V
Voltage unit
3
Digital
display
zone
Five-digit LED displays various monitoring data and alarm codes such as
the frequency setting and output frequency.
Display
Means
Display
Means
Display
Means
Display
Means
0
0
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
A
A
B
B
c
C
D
D
E
E
F
F
H
H
i
I
L
L
N
N
n
n
o
o
P
P
r
r
5
S
t
t
U
U
V
v
.
.
-
-
4
Keys
PRG
ESC
Programming
key
Press it to enter or exit level-1 menus or delete a
parameter.
DATA
ENT
Confirmation
key
Press it to enter menus in cascading mode or
confirm the setting of a parameter.
Up key
Press it to increase data or move upward.
Down key
Press it to decrease data or move downward.
SHIFT
Right-shifting
key
Press it to select display parameters rightward in
the interface for the inverter in stopped or
running state or to select digits to change during
parameter setting.
RUN
Run key
Press it to run the inverter when using the
keypad for control.
STOP
RST
Stop/
Reset key
Press it to stop the inverter that is running. The
function of this key is restricted by P07.04. In
