INVT SPC Series User Manual

SPC Series Solar Pump Inverter Function parameter list
-24-
Function
code
Name
Description
Default
Modify
P02.03
Rated speed of
AM
1–36000rpm
the parameter
autotuning function.
Whether parameter
autotuning can be
performed properly
depends on the settings
of the motor nameplate
parameters.
In addition, you need to
configure a motor
according to the
standard motor
configuration of the
inverter. If the power of
the motor is greatly
different from that of the
standard motor
configuration, the
control performance of
the inverter degrades
significantly.
Note: Resetting the
rated power of the
motor (P02.01) can
initialize the parameters
P02.02–P02.10.
Model
depended
◎
P02.04
Rated voltage
of AM
0–1200V
Model
depended
◎
P02.05
Rated current
of AM
0.8–6000.0A
Model
depended
◎
P02.06
Stator
resistance of
AM
0.001–65.535Ω
After motor parameter
autotuning is properly
performed, the values
of P02.06–P02.10 are
automatically updated.
These parameters are
the benchmark
parameters for
high-performance
vector control, directly
affecting the control
Model
depended
○
P02.07
Rotor
resistance of
AM
0.001–65.535Ω
Model
depended
○
P02.08
Leakage
inductance of AM
0.1–6553.5mH
Model
depended
○
P02.09
Mutual
inductance of
AM
0.1–6553.5mH
Model
depended
○
