SV-DA200 series AC servo drive Function codes
-137-
Note: The default value is the function selection corresponds to position mode.
P3.10
1
Data size
16bit
Data format
HEX
Modbus address
1620, 1621
CANopen address
0x230A, 0x00
P3.11
1
Output configuration of digital 2
Setting range
Default
Unit
Available mode
0x0000x11F
0x003
-
P
S
T
P3.12
1
Output configuration of digital 3
Setting range
Default
Unit
Available mode
0x0000x11F
0x007
-
P
S
T
P3.13
1
Output configuration of digital 4
Setting range
Default
Unit
Available mode
0x0000x11F
0x00D
-
P
S
T
P3.14
1
Output configuration of digital 5
Setting range
Default
Unit
Available mode
0x0000x11F
0x005
-
P
S
T
P3.15
1
Output configuration of digital 6
Setting range
Default
Unit
Available mode
0x0000x11F
0x00E
-
P
S
T
These parameters are used to set the output function of digital value 26, and they are hex
numbers.
The setting method is the same as P3.10.
Note: The default value is the function selection corresponds to position mode.
P3.11
1
Data size
16bit
Data format
HEX
Modbus address
1622, 1623
CANopen address
0x230B, 0x00
P3.12
1
Data size
16bit
Data format
HEX
Modbus address
1624, 1625
CANopen address
0x230C, 0x00
P3.13
1
Data size
16bit
Data format
HEX
Modbus address
1626, 1627
CANopen address
0x230D, 0x00
P3.14
1
Data size
16bit
Data format
HEX
Modbus address
1628, 1629
CANopen address
0x230E, 0x00
P3.15
1
Data size
16bit
Data format
HEX
Modbus address
1630, 1631
CANopen address
0x230F, 0x00
P3.16
Function configuration of
DI capture encoder
Setting range
Default
Unit
Available mode
0778
0
-
P
S
T
DI port capture function configuration, capture the encoder position via the jump edge of DI port
in real time, check encoder value captured via R1.16.
Data bit
Setup instruction
Remark
bit03
bit03=0x10xA, corresponds to capture port DI1DI10
Others are
invalid state
bit89
bit8=1, bit9=0, capture only on DI port falling edge;
bit8=0, bit9=1, capture only on DI port rising edge;
bit8=1, bit9=1, capture on both DI port rising edge and falling edge.
P3.16
Data size
16bit
Data format
DEC
Modbus address
1632, 1633
CANopen address
0x2310, 0x00
