SV-DA200 series AC servo drive Control mode applications
-59-
Signal name
Sign
Function number
Available mode
Gantry synchronization input clear
GIN
0x2D
P
When this digital input is valid, gantry synchronous is removed.
Signal name
Sign
Function number
Available mode
Master gantry synchronization alignment
sensor
GSM
0x2E
P
Master gantry synchronization alignment sensor
Signal name
Sign
Function number
Available mode
Slave gantry synchronization alignment
sensor
GSS
0x2F
P
Slave gantry synchronization alignment sensor
Signal name
Sign
Function number
Available mode
Dynamic braking relay feedback
DBS
0x30
P
S
T
When this digital input is valid, the dynamic braking relay will be closed.
Signal name
Sign
Function number
Available mode
Manual and automatic switching of turret
DAT
0x31
P
When this digital input is valid, the turret is manual mode.
Signal name
Sign
Function number
Available mode
Forward jogging of turret
DFJ
0x32
P
When this digital input is valid, the turret is forward jogging.
Signal name
Sign
Function number
Available mode
Reverse jogging of turret
DRJ
0x33
P
When this digital input is valid, the turret is reverse jogging.
Signal name
Sign
Function number
Available mode
Switching between fully-closed loop and
semi-closed loop
FCS
0x34
P
This function is valid only when P0.38 [enable fully-closed loop] is set to 2 [enable].
When this digital quantity is valid, it is semi-closed loop; if invalid, it is fully-closed loop
Signal name
Sign
Function number
Available mode
PTP terminal pause
PSTOP
0x35
P
When this digital input is valid, jog control operation pauses.
Signal name
Sign
Function number
Available mode
EzJOG terminal pause
ESTOP
0x36
P
When this digital input is valid, EzJOG operation pauses.
