INVT SV-DA200-2R0-4 - Position Latch Save Mode; Forward High JOG Speed; Reverse High JOG Speed; Terminal JOG Valid

SV-DA200 series AC servo drive Function codes
-177-
Position latch function switch can be set via this parameter. After this function is enabled, the
position information will be saved in EEPROM after each terminal latch, however, too frequent
saving operation may damage the EEPROM.
Setting value
Function
[0]
Disabled
1
Enabled
P6.02
1
Data size
16bit
Data format
DEC
Modbus address
2204, 2205
CANopen address
0x2602, 0x00
P6.03
Position latch save mode
Setting range
Default
Unit
Available mode
0–1
0
-
P
Position latch save mode can be set via this parameter:
Setting value
Function
[0]
Do not save
1
Save
P6.03
Data size
16bit
Data format
DEC
Modbus address
2206, 2207
CANopen address
0x2603, 0x00
P6.04
Forward high JOG speed
Setting range
Default
Unit
Available mode
0–6000
60
r/min
P
This parameter is used to set the speed of fast forward jogging which is triggered by forward
jogging terminal and switching terminal of high-low jogging speed.
P6.04
Data size
16bit
Data format
DEC
Modbus address
2208, 2209
CANopen address
0x2604, 0x00
P6.05
Reverse high JOG speed
Setting range
Default
Unit
Available mode
-6000–0
-60
r/min
P
This parameter is used to set the speed of fast reverse jogging which is triggered by reverse
jogging terminal and switching terminal of high-low jogging speed.
P6.05
Data size
16bit
Data format
DEC
Modbus address
2210, 2211
CANopen address
0x2605, 0x00
P6.06
Terminal JOG valid
Setting range
Default
Unit
Available mode
0–1
0
-
P
This parameter is used to set terminal JOG function:
Setting value
Function
[0]
Invalid
1
Valid
P6.06
Data size
16bit
Data format
DEC
Modbus address
2212, 2213
CANopen address
0x2606, 0x00
