SV-DA200 series AC servo drive Installation instruction
-22-
2.3 Motor dimension
Note: As motor structure and dimension may vary slightly with design modification, for those who are
sensitive to the installation length of motor, please confirm the installation length with our business
staff before ordering.
2.3.1 Outline and installation dimension for 40 base (mm)
L25
Φ8h7
Φ30h7
3
4-Φ3.5
Φ46
40
40
15
3h9
9.2
M3 depth 6
A
A
A-A
Motor model
(2500-PPR/multi-turn absolute value)
L(mm)
W/o brake
Permanent magnet brake
SV-ML04-0R1G-2-A
90
124
####
Φ30h7
14
Φ8h7
L
3
25.5 40
40
3h9
9.2
M3 depth 6
2-Φ4.5
Φ46
A
A
A-A
Motor model
(17-bit single-turn encoder)
L(mm)
W/o brake
Electromagnetic brake
SV-ML04-0R1G-2-3A
90.3
123
