iPECS eMG80 & eMG800 & UCP
Feature Description and Operation Manual Issue 1.6
123
TABLES DATA
Voice Mail Dialing Table
MAINTENANCE
TRACE
Virtual Dip Switch SMDI Setting
Related Features
 AA/VM Group
 SMDI (Simplified Message Desk Interface)
 Auto Call Recording
 Two-Way Record
 Integrated Auto Attendant/Voice Mail
Hardware
 External AA/VM system
2.38.3 SMDI (Simplified Message Desk Interface) AA/VM Signaling
Description
The system may employ SMDI (Simplified Message Desk Interface) protocol to communicate
with an adjunct AA/VM system. When a call is routed to an AA/VM SLT port, the system will send
SMDI messages over the assigned SMDI RS-232 port, informing the AA/VM of the
characteristics of the call.
There are three types of SMDI messages. Within each message is an “Action Code”, which
defines the function or required action of the AA/VM system. Fields within the messages also
define the called/calling station and station status. The various message types and definition of
the fields are shown in the chart below.
SMDI Protocol
Type I message
cr lf MD ggg mmmm a xxxxxxxxx sp yyyyyyyyy sp cr lf^Y
Type II message
cr lf MD ggg mmmm a xxxxxxxxx sp sp cr lf^Y
Type III message
cr lf MD ggg mmmm a sp yyyyyyyyy sp cr lf^Y
Field
Description
cr
carriage return
lf
line feed
MD
Message Desk
ggg
Message desk number, AA/VM system, default 001
