4.14.3 Keypad Facility
Description
The ISDN Keypad Facility Information Element (IE) may enable the user to activate certain ISDN
services (e.g. Off-Net Forward). To access this facility, the station must be enabled and have a
{KEYPAD FACILITY} Flex button. When activated, the digits dialed by a user are sent in the
Keypad Facility IE instead of the Called Party Number IE.
Operation
iPECS IP & LDP Phones
[TRANS/PGM] + {FLEX} + [TRANS/PGM] + “89” + [HOLD/SAVE]
To program {KEYPAD FACILITY} button
1. Press the {KEYPAD FACILITY} button.
To activate the keypad facility while on an ISDN line
2. Dial desired digits; other actions disable the Keypad facility feature.
Conditions
1. This feature can be activated or deactivated only after an ISDN Line is seized.
2. Once activated, the system will continue to send dialed digits as Keypad Facility IE
messages regardless of other ISDN messages. Thus, in the connected mode, DTMF
tones are not sent to the connected party, only the keypad message is sent.
3. If a Speed Dial bin includes the [MESSAGE/CALLBACK] button as the first entry, the
remaining digits in the Speed Dial number are sent in a Keypad Facility IE.
4. This feature may not be available in the specific ISDN or may be a subscription service.
5. The system can handle only a single Call Reference; services that require handling of
two simultaneous Call References, cannot be supported.
Programming
Keyset Admin.
STATION
Flex Button Assignment (PGM 115)
STATION DATA
Web Admin.
Flexible Buttons
Related Features
 Station Speed Dial
 System Speed Dial
Hardware
 iPECS IP or LDP Phone
 ISDN Line
