4.18 Outside Line Groups
Description
The outside Lines, in the system can be placed together into groups for assigning access by
stations and common access dial codes as well as to separate the type of Line (analog, digital or
IP). There are 20 Line groups in eMG80 and there are 200 Line groups in eMG800/UCP.
Unused Lines are assigned to Group 21 in eMG80 and to Group 201 in eMG800/UCP. Private
Lines are assigned to Group 00.
Operation
Conditions
1. Unused outside Lines must be assigned to the appropriate group so that stations do
not accidentally access these lines.
2. Outside Lines in Groups 01 through 20 for eMG80 and Groups 01 through 200 for
eMG800/UCP can be accessed individually by dialing the code “88” and the Line
number.
3. An outside Line in Group 00 can be accessed only with a Flex button assigned to the
Line.
4. The system will select an outside Line from a group based on the Round Robin or Last
Choice method as configured in the system database.
Programming
Keyset Admin.
STATION CO PGM (PGM 112-Button 6)
CO/IP Group Access (PGM 117)
CO/IP
CO/IP Group (PGM 141-Button 1)
SYSTEM
CO Line Choice (PGM 160-Button 4)
STATION DATA
Web Admin.
Common Attributes  CO PGM
CO/IP Group Access
CO LINE DATA
Common Attributes

CO/IP Group
SYSTEM DATA
System Attributes

CO Line Choice
Related Features
Hardware
