 | LaserNet software
98
YLS-K
Item Description
4 In the laser program tab section, you can select a laser program
(number 1-50), start/stop the current program and monitor its sta-
tus. In the input field Number
, enter the desired laser program. Click
on the button Start program
to start the laser program. Upon start-
ing the laser program, the name and the function of the button Start
program change to Stop program . At the same time, the status indi-
cator Program active is activated and remains active until the pro-
gram ends. If the program ends without an error, the status indicator
End of program is activated. The status indicator remains active until
you start a new program or click on the button Reset
. The name and
the function of the button Stop program
change again to Program
Start when the program ends. Clicking on the button Stop program
while the program is running stops the program and activates the
status indicator Program interrupted. With the button Reset
, you can
deactivate the status indicator Program interrupted.
5 By clicking on this button, you can switch the laser power supply on
and off (ON/OFF).
6 By clicking on this button, you can switch the laser emission on and
off (ON/OFF).
7 With the button Reset , you can reset all alarms, except for the mes-
sage Reset critical error once the reason for the alarm has been re-
moved.
8 By clicking on this button, you can switch the external control on and
off. The status is indicated on the button itself.
9 In the tab section Ramping time, you can set the ramping rise and fall
times. Enter the desired value (max. 5000 ms) into the corresponding
input field and confirm your entry with the Enter
key or by clicking
on the button Set
.
10 By clicking on this button, you can switch the analog control on and
off. The current status is indicated on the button itself.
Table13: Control tab description
