Ref.
No. Part No. Description
1 SB-00915-0 Screw, #10-16 self drilling
* 2 TUD0476WH Front panel - Lower coin
TUD0477WH Front panel - Lower opl
3 TU3213 Pop rivet
4 TU2876 Door catch
5 TU14992 Insulation ( 3 pcs)
6 TU7733 Screw #8 Self tapping
7 SB-00852-0 Washer star
8 CA-00699-0 Coin box bezel (some models)
9 ESA-00862-0 Reed switch
10 SB-00975-0 Screw #6-32
* 11 TUD0475WH Front panel - Upper
12 SB-00836-0 Screw #10 pancake
FRONT PANEL ASSEMBLY
(See previous page)
* TUD0480WH - Front panel assembly complete -Upper
* TUD0481WH - Front panel assembly complete - Lower coin
* TUD0482WH - Front panel assembly complete - Lower opl
* Please specify color
