Page 55
PARTS - TUMBLER ASSEMBLY
REAR CONTROL BOX
Ref. Part
No. No. Description
1 TU7733 SCREW SELF TAP
2 GA-00765-0 SPARK MODULE 24V (US)
TU14675 SPARK MODULE 24V(AUST)
GA-11007-0 SPARK MODULE 24 (CE)
3 GA-00803-0 HI-VOLT CABLE
4 TU2372 SNAP BUSHING
5 TU2490 PLUG
6 TU15138 TRANSFORMER 120V/200-240V
7 TU13516 CONTACTOR-24V 9AMP
8 TUD0243 COVER, REAR CTL/BOX
9 TUD0315 PLATE-CONTROL PNL
To Next Page
