Page 41
Ref. Part
No. No. Description
1 LA-00121-0 LOCK AND KEY CONTROL
2 CA-00748-0 TRIM, BOTTOM ALM
3 TUD0234WH COVER PLT W/A
4 SB-00951-0 SCREW #8
5 TU2853 LINT DRAWER GASKET
6 TUD00366 MAGNET SNAP CATCH
7 TU7858 LABEL, INSTRUCTIONS
8 CA-00749-0 TOP TRIM, ALM
PARTS - TUMBLER ASSEMBLY
CONTROL PANEL
