ISOMAG ML 110 - MENU 6 - OUTPUTS CONFIGURATION; Function Choice for Outputs; Current Output Option and Range

30
FUNCTIONS FOR OUTPUTS 1 AND 2
 OFF: DISABLED
 #1 IMP+: PULSE ON CHANNEL 1 FOR POSITIVE FLOW RATE
 #1 IMP-: PULSE ON CHANNEL 1 FOR NEGATIVE FLOW RATE
 #1 IMP: PULSE ON CHANNEL 1 FOR POSITIVE AND NEGATIVE FLOW RATE
 #2 IMP+: PULSE ON CHANNEL 2 FOR POSITIVE FLOW RATE
 #2 IMP-: PULSE ON CHANNEL 2 FOR NEGATIVE FLOW RATE
 #2 IMP: PULSE ON CHANNEL 2 FOR POSITIVE AND NEGATIVE FLOW RATE
 #1 FREQ+: FREQUENCY CHANNEL 1 FOR POSITIVE FLOW RATE
 #1 FREQ-: FREQUENCY CHANNEL 1 FOR NEGATIVE FLOW RATE
 #1 FREQ: FREQUENCY CHANNEL 1 FOR POSITIVE AND NEGATIVE FLOW RATE
 #2 FREQ+: FREQUENCY CHANNEL 2 FOR POSITIVE FLOW RATE
 #2 FREQ-: FREQUENCY CHANNEL 2 FOR NEGATIVE FLOW RATE
 #2 FREQ: FREQUENCY CHANNEL 2 FOR POSITIVE AND NEGATIVE FLOW RATE
 SIGN: FLOW DIRECTION OUTPUT (ENERGIZED = -)
 RANGE: RANGE INDICATION OUTPUT (ENERGIZED = SCALE 2)
 MAX AL.: MAX FLOW RATE OUTPUT(ENERGIZED = AL. OFF)
 MIN AL.: MIN FLOW RATE OUTPUT(ENERGIZED = AL. OFF)
 MAX+MIN: MAX AND MIN FLOW RATE ALARM OUTPUT (ENERGIZED = AL. OFF)
 P. EMPTY: EMPTY PIPE ALARM OUTPUT (ENERGIZED = FULL PIPE)
 OVERFLOW.: OUT OF RANGE ALARM OUTPUT (ENERGIZED = FLOW RATE OK)
 HARDW AL.: CUMULATIVE ALARM OUT interrupt coils, empty pipe, measure error (ENERGIZED=NO ALARM)
MENU 6 - OUTPUTS
(POS. 6.1) Function choice corresponding to on/off output 1 [Out
1=XXXXXX]
Function choice corresponding to digital Output 1. The functions are listed in the table below.
(POS. 6.2) Function choice corresponding to on/off output 2 [Out
2=XXXXXX]
Function choice corresponding to digital Output 2. The functions are listed in the table below.
(POS. 6.3) Current output option and range [Out mA=X_XX XXX]
This function sets the current output N.1. This function is optional and will not appear unless the
option has been requested. There are three fields to modify for this function:
 Scale zero: 4 or 0mA
 Full scale: 20 or 22mA
 Field: + = positive, - = negative, blank = both, -0+ = central zero scale
The values corresponding to the scale points are shown in the following chart:
In hardware alarm conditions “HARDW AL.” (interrupted coils, empty pipe, measure error) the
current value is programmed by the function “mA v.fault” (pos. 4.4) and it is expressed as
percentage of a fixed current range, where: 0% = 0mA and 110% = 22mA.
CURRENT VALUES IN mA ASSOCIATE TO THE % FULL SCALE VALUE
POSSIBLE FIELD
REVERSE FLOW VALUE ZERO DIRECT FLOW VALUE
 -110% -100% 0% +100% +110%
OutmA = 0 - 20 + 0 0 0 20 20
OutmA = 0 - 22 + 0 0 0 20 22
OutmA = 4 - 20 + 4 4 4 20 20
* OutmA = 4 - 22 + 4 4 4 20 22
OutmA = 0 - 20 - 20 20 0 0 0
OutmA = 0 - 22 - 22 20 0 0 0
OutmA = 4 - 20 - 20 20 4 4 4
OutmA = 4 - 22 - 22 20 4 4 4
OutmA = 0 - 20 20 20 0 20 20
OutmA = 0 – 22 22 20 0 20 22
OutmA = 4 - 20 20 20 4 20 20
OutmA = 4 – 22 22 20 4 20 22
OutmA = 0 - 20 –0+ 0 0 10 20 20
OutmA = 0 - 22 –0+ 0 1 11 21 22
** OutmA = 4 - 20 –0+ 4 4 12 20 20
OutmA = 4 - 22 –0+ 4 4.8 12.8 20.8 22
