19
Flue duct
or chimney
Combuson
products
test point
min. 1000 mm
max. 2500 mm
Minimum
slope 5%
D
min.
2 x D
NO
NO
YES
00031 00
B
11BS
Model Diameter D of the ue pipe
City Basic 24 C 130 mm
The boiler is ed with a safety thermostat for the ue ow detecon, that triggers when the
combuson products reow into the room. This device must never be bypassed or put out of
Combuson products could lead to intoxicaon, permanent damage and death. If the

In case of repeated intervenons of the device (and consequent boiler locks), check that the air
supply / room venlaon system and the Flue Products Outlet System are ecient and made
according to the laws in force.
 
(by momentarily
In case of ue outlet on wall, the posions and the distances prescribed by the regulaon mist be re-
spected (see "Flue terminals posioning" on page 20).
