Italtherm CITY BASIC - Boiler Internal Components

36
Boiler internal components
1415 1316 12
5
17
18
19
8
10
11
6
7
20
3
4
9
2
1
00034 00
1 Flue thermostat
2 Flue hood
3 Safety thermostat for
max. water temperature
4 Expansion vessel
5 Ignion electrode
6 DHW temperature sensor
7 Flame sense electrode
8 Electronic igniter
9 Automac venng device
(incorporated in the pump)
10 Safety valve 3 bar
11 Gas valve
12 System pressure gauge
13 Priority ow switch (with lter)
14 Filling valve
15 Drain valve
16 Loss of water pressure switch
17 Pump
18 Heang circuit temperature sensor
19 Burner
20 Bithermic exchanger
