Functions and Features
• On Sync Out: As the indication signal of the instrument output status. When
the output is OFF, the pins output 0V low level; when the output is ON, the
pins output 5V high level.
• On Sync In: Used to control the output state of the instrument. Input 0V low
level to the pins, the instrument output is OFF; input 5V high level to the pins,
the instrument output is ON.
The procedures to set the menu item are as follows.
1. Press [Shift]+[Display] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Ext IO and press [Enter]
key to make the parameter in modification.
3. Rotate the knob to set and press [Enter] key to confirm.
4.2.5 Restore the Factory Default Settings
This menu item is used to restore the factory default settings.
The procedures to set the menu item are as follows.
1. Press [Shift]+[Display] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select System Reset and press
[Enter] key to make the parameter in modification.
3. Use left and right keys or rotate the knob to select the value from the follow-
ing options.
• No: default value, indicates the power supply cancels this menu setting.
• Yes: indicates the power supply restores the factory default settings.
4. After finishing the setting, press [Enter] key to confirm.
The detailed default parameters are listed in the following table.
No. Parameter Default Value
The setting values on the front panel
1
Voltage
0
2 Current MAX
Config menu
1 Mode
CV Priority
2 V-Rise Time 0.001 S
3 V-Fall Time 0.001 S
4 I-Rise Time 0.001 S
Copyright © Itech Electronic Co., Ltd.
50
