ITech IT-M3900C Series User Manual

Technical Specification
Power Factor 0.99
DC component
≤0.2A
Current harmonics ≤3%
Standard Interface
Standard: USB/LAN/CAN/IO Optional: GPIB/Analog/RS232
Command Re-
sponse Time
0.1ms
Parallel Number ≤16
Working
Temperature
0～40℃
Storage
Temperature
-10℃～70℃
IP IP20
Isolation DC to GND 300Vdc
Isolation AC to GND 3500Vdc
Cooling
Air
Dimension ( mm)
660mm*437mm*43.5mm
Weight( net) 15kg
6.1.4 IT-M3910C-10-1020
Parameter IT-M3910C-10-1020
Rated value
Voltage
0～10V
Current -720A～1020A
Power -7200W～10200W
Resistance in series
（CV priority）
0～0.02Ω
Load resistance
（CC priority）
0.00015Ω～0.5Ω
Setup Resolution
Voltage
0.001V
Current 0.1A
Power 1W
Resistance in series
（CV priority）
0.001Ω
Load resistance
（CC priority）
0.001Ω
Copyright © Itech Electronic Co., Ltd.
179
