Getting Started
3.2 Set Output Value
The voltage value, current value, power value can all be programmed. The user
can set different output parameters within the range of specifications according
to the need to satisfy a range of test requirement.
After selecting the operation mode, the interface displays the setting value
under the selected operation mode and the cursor blinks to prompt. The user
can use the following methods to set the values.
• Directly use the number keys to set the value.
• Rotate the knob to set the data in the cursor position. Rotate the knob clock-
wise to increase the set value and anticlockwise to decrease the set value.
Once the data in the cursor position increases to ten, the value will add one
to the front position automatically. and once the data in the cursor position
decreases to zero, the value will minus one from the front position automati-
cally. This provides convenience for the user to set. The knob can works with
the left or right keys. Use the left or right keys to move the cursor position.
After entering the menu interface, the knob can also be used to scroll pa-
ges to view menu items.
3.3 Use the Front Panel Menu.
The front panel provides multiple menu keys and the user can access the instru-
ment menu by using the front panel keys, including Config menu, System
menu, Protect menu and Function menu. And the user can change the related
system setting in the menu. Each menu is briefly described as follows.
• The user can set the parameters related to electrical properties in the
Config menu, including the current operation mode, slope, output delay
time, internal resistance.
• The user can set the function related to instrument system in the System
menu, including the key beeper, Sense function, power-on state, trigger
source, communication method, data logger method, digital I/O function set-
ting, parallel function, system information and so on.
• The user can set the parameters related to instrument protection function in
the Protect menu, including OCP /OVP/OPP /UCP/UVP.
• Function menu includes output list, batterycharging test function and so on.
Copyright © Itech Electronic Co., Ltd.
45
