Power Supply Function

5. Based on the selected trigger method, perform the trigger operation.

The trigger method of the SAS function is consistent with the trigger

method of the List function, that is, the List trigger source is also effec-

tive for the SAS function.

Stop Running the Static PV Curve

If you want to stop running during the SAS test, you can do the following: Press

the composite keys [Shift]+[I-set] (Function) on the front panel to enter the

function menu.

At this point, the interface will prompt whether to stop the running of the Func-

tion, you can press the Left/Right key to select Stop, then the running will be

stopped, and the Function menu item will be displayed, you can re-enter the

Function menu for editing; if Reset is selected, it means to stop the present run-

ning and return to the main interface to wait for the next trigger operation.

4.6.5 Battery Simulation Function

This series power supply can simulate battery characteristics in practical appli-

cations based on its unique bidirectional properties and the variable output im-

pedance. You can set battery-related parameters to simulate the charge and

discharge characteristics of the battery to assist with other tests. The menu

items for this function are described below:

Battery

Emulator

Battery simulation function

User-

define

Select a user-defined battery simulation file for

testing.

Run

Run the currently selected user-de-

fined battery simulation file.

Initial Value

• Set the initial state of

charge (SOC) of the

battery. 0~100% cor-

responds to the volt-

age range from no-

load voltage to full-

load voltage.

121

ITech IT-M3900C Series User Manual
