Power Supply Function
3. Press the Left/Right key to select Static and press [Enter].
4. Press the Left/Right key to select Curve and press [Enter].
5. Press the Left/Right key to select Open and press [Enter].
6. Set the name of the Curve file to be recalled (i.e. the file name set in Edit)
and press [Enter].
At this point, the system returns to the main interface of the SAS function,
and the currently selected Curve file is to be run. The interface is displayed
as follows:
FUNCTION SAS
Run Vmax Static Table Filter
Run the Static PV Curve
• Curve
1. Refer to Select Curve file to select the Curve file to be run.
2. Set the Vmax (in Config menu) and Filter as the actual test needs.
3. Press the Left/Right key on the SAS main interface to select Run and
press [Enter].
At this point, the instrument enters the SAS mode, and the VFD screen is
displayed as the main interface of the system, waiting to trigger the Curve
file to run.
4. Turn on the [On/Off].
5. Based on the selected trigger method, perform the trigger operation.
The trigger method of the SAS function is consistent with the trigger
method of the List function, that is, the List trigger source is also effec-
tive for the SAS function.
• User-defined
1. Refer to the User-defined related contents in the Edit Static PV Curve to
finish editing the custom curve.
2. Set the Vmax (in Config menu) and Filter as the actual test needs.
3. Press the Left/Right key on the SAS main interface to select Run and
press [Enter].
At this point, the instrument enters the SAS mode, and the VFD screen is
displayed as the main interface of the system, waiting to trigger the
User-defined curve to run.
4. Turn on the [On/Off].
Copyright © Itech Electronic Co., Ltd.
120
